MIL-W-2796 2796 nm All-Solid-State Mid-Infrared Laser
$1,000,000.00
Description: LD pumped all-solid-state infrared laser at 2796 nm (the "water laser") with good beam quality and easy operation. Its wavelength is strongly absorbed by water, enabling medical procedures without a shot or a drill.
Applications: medical treatment (water-laser dentistry and surgery), scientific research
Model #: MIL-W-2796
| Wavelength (nm) | 2796±3 |
| Operating Mode | CW |
| Output Power (mW) | 10-300 |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Transverse Mode | Near TEM00 |
| Beam Divergence, Full Angle (mrad) | <8 |
| Beam Diameter at the Aperture (1/e2, mm) | <3 |
| Warm-up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 98 |
| Cooled Method | Air Cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (100-240 VAC) | PSU-H-LED |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MIL-W-2796
Please request a quotation for a real price and lead time.
