MIL-W-3800 3800 nm CW Mid-Infrared Laser
$1,000,000.00
Description: LD pumped all-solid-state mid-infrared laser at 3800 nm featuring high power, long lifetime and easy operating, widely used in material processing especially for plastics, FSO communication and security applications.
Applications: material processing (plastics), FSO communication, security applications
Model #: MIL-W-3800
| Wavelength (nm) | 3800±30 |
| Operating Mode | CW |
| Output Power (mW) | 250-1000 / 1000-2800 (two versions) |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3%, (<1% optional @ 2.8 W) |
| Beam Divergence, Full Angle (mrad) | <10 / <8 |
| Beam Diameter at the Aperture (1/e2, mm) | <10 / <12 |
| Beam Height from Base Plate (mm) | 103 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air Cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (100-240 VAC) | RAD1PS |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MIL-W-3800
Please request a quotation for a real price and lead time.
