MLL-III-915-SM 915 nm Low Noise Single Mode Fiber Coupled Infrared Diode Laser
$1,000,000.00
Description: Single mode fiber coupled low noise infrared diode laser at 915 nm featuring ultra compact design, long lifetime, cost-effectiveness and easy operation.
Applications: medical imaging, flow cytometry, DNA sequencing, etc.
Model #: MLL-III-915-SM
| Central Wavelength (nm) | 915±10 |
| Operating Mode | CW |
| Output Power After Fiber (mW) | 1-400 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Fiber Type | SM fiber, PM fiber optional |
| Fiber Core Diameter | 4-9 μm, 0.12 NA |
| Fiber Connector | FC/PC, FC/APC optional |
| Fiber Length | 1 m |
| Fiber Jacket | Metal, PVC optional |
| Transverse Mode | TEM00 |
| Noise of Amplitude (rms, 20 Hz-20 MHz) | <1%, <0.5% |
| Ellipticity | >0.95 |
| M2 After Fiber | ~1.1 |
| Warm-up Time (minutes) | <5 |
| Cooling Method | Conduction |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MLL-III-915-SM
Please request a quotation for a real price and lead time.
