MLL-XS-561 561 nm LD Pumped All-Solid-State Low Noise Yellow Green Laser
$1,000,000.00
Description: Low noise yellow green laser at 561 nm is made features of ultra compact, small size, wide operating temperature, good sealing, long lifetime, cost-effectiveness and easy operating.
Applications: flow cytometry, scientific experiment, optical sensor, measurement, instrument, communication, spectrum analysis
Model #: MLL-XS-561
| Model | MLL-XS-561 |
| Model | MLL-XS-561 |
| Wavelength (nm) | 561±1 |
| Operating Mode | CW |
| Output Power (mW)¹ | 1-80 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Transverse Mode | TEM00 |
| Noise of Amplitude (rms, 20Hz-20MHz) | <1% (<0.5%, 0.25% optional) |
| M² | <1.2 |
| Beam Diameter at the Aperture (1/e², mm) | ~0.7 |
| Beam Divergence (mrad) | <1.0 |
| Polarization Ratio | >100:1 (Vertical ±5 degree) |
| Warm-Up Time (minutes) | <5 |
| Pointing Stability (µrad, over 2 hours after warm-up and ±3°C) | <50 |
| Beam Height from Base Plate (mm) | 19 |
| Operating Temperature (℃) | 10-35 |
| Operating Voltage (VDC) | 12 |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MLL-XS-561
Please request a quotation for a real price and lead time.
