MPL-H-1319 1319 nm Passively Q-Switched Solid-State Laser
$1,000,000.00
Description: All-solid-state passively Q-switched laser at 1319 nm with high peak power, high repetition rate and short pulse duration.
Applications: industry (marking on diamond or stone), teaching of nonlinear optics, fiber communication
Model #: MPL-H-1319
| Wavelength (nm) | 1319±1 |
| Operating Mode | Passively Q-switched |
| Average Power (mW) | 100-150 |
| Single Pulse Energy (µJ) | 7-15 |
| Pulse Duration (ns) | ~15 |
| Peak Power (kW) | 0.5-1 |
| Repetition Rate (Internal Trigger) | 1 Hz-4 kHz |
| Repetition Rate (External Trigger) | 1 Hz-4 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Transverse Mode | TEM00 |
| M2 | <1.5 |
| Beam Diameter at the Aperture (mm) | ~1.5 |
| Beam Divergence, Full Angle (mrad) | <2.0 |
| Polarization Ratio | >100:1, Horizontal (Vertical optional) |
| Warm-up Time (minutes) | <5 |
| Beam Height from Base Plate (mm) | 29 |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-H-FDA |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MPL-H-1319
Please request a quotation for a real price and lead time.
