213 nm LD Pumped All-Solid-Sate Passively Q-switched Pulsed Laser MPL-S-213-HP
$1,000,000.00
Description: All-solid-state passive lasers feature high peak power and short pulse duration.
Applications: scientific research, laser micromachining, lidar ranging, environmental monitoring, laser ultrasonic testing and LIBS
Model #: MPL-S-213-HP
| Model | MPL-S-213-HP |
| Wavelength | 213 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | ~50 / ~40 / ~30 / ~20 mW |
| Single Pulse Energy | ~0.5 / ~1 / ~7.5 / ~20 µJ |
| Pulse Width | ~500 / ~700 / ~800 / ~400 ps |
| Peak Power | 1 / 1.4 / 7.5 / 50 kW |
| Repetition Rate | QCW ~100 / ~40 kHz; Int/Ext 1-4 / 0.01-1 kHz |
| Beam Height from Base Plate | 46 / 37 mm |
| Cooling Method | Fan cooled |
| Power Stability | <5%, <3% |
| Transverse Mode | Near TEM00 |
| M2 | / |
| Beam Diameter at the Aperture | ~1.5 mm |
| Beam Divergence, Full Angle | <1.5 mrad |
| Warm-Up Time | < 5 min. |
| Operating Temperature | 10 ~ 35 ℃ |
| Power Supply (100 - 240 VAC) | PSU-S-HP |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MPL-S-213-HP
Please request a quotation for a real price and lead time.
