MPL-T-1535 1535 nm Passively Q-Switched Solid-State Laser
$1,000,000.00
Description: All solid state passively Q-switched laser at 1535 nm featuring high peak power and short pulse duration.
Applications: scientific research, laser micromachining, laser radar ranging, environment monitoring, laser ultrasonic monitoring and LIBS (Laser Induced Breakdown Spectroscopy)
Model #: MPL-T-1535
| Wavelength (nm) | 1535±2 |
| Operating Mode | Passively |
| Average Power (mW) | 0.1-1 / 0.2-2 / 0.3-3 / 0.4-4 / 40 |
| Single Pulse Energy (µJ) | 100 / 200 / 300 / 400 / 40 |
| Pulse Duration (ns) | 3-6 / 3-5 |
| Peak Power (kW) | 25 / 50 / 70 / 80 / 10 |
| Rep. Rate (Hz) | 1-10 (external triggered) / 1000 |
| Energy Stability (rms, 4 hours ± 3°C) | <5% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | ≤12 / ≤15 |
| Warm-up Time (minutes) | <5 |
| Beam Height from Base Plate (mm) | 22 |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-SR |
| Power Supply (5 VDC) | PSU-T-OEM-II (5V/5A) |
| Expected Lifetime | >10⁷ times irradiate / >2×10⁷ times irradiate |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MPL-T-1535
Please request a quotation for a real price and lead time.
