MSL-FN-607 607 nm Single Longitudinal Mode Red Laser
$1,000,000.00
Description: All solid state red at 607nm is made features of ultra compact, long lifetime and easy operating, which is widely used in brillouin scattering, measurement, spectrum analysis as the substitute for He-Ne lasers.
Applications: brillouin scattering, measurement, spectrum analysis (substitute for He-Ne lasers)
Model #: MSL-FN-607
| Wavelength (nm) | 607±1 |
| Operating Mode | CW |
| Output Power (mW) | >1, 5, 10, 20, … , 100 |
| Power Stability (rms, over 4 hours) | <1%, <2%, <3% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | Single |
| Spectral Linewidth (nm) | <0.00001 |
| Coherent Length (m) | >50 |
| Noise of Amplitude (rms, 1Hz~20MHz) | <1% |
| M² Factor | <1.2 |
| Beam Diameter at Aperture (1/e², mm) | <1.5 |
| Beam Divergence, Full Angle (mrad) | <1.2 |
| Polarization Ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up Time (minutes) | <10 |
| Pointing Stability After Warm-up (mrad) | <0.05 |
| Beam Height from Base Plate (mm) | 27.4 |
| Operating Temperature (℃) | 15~35 |
| Power Supply (90-264VAC) | PSU-H-FDA |
| Expected Lifetime (hours) | 10000 |
| Warranty | 1 year |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MSL-FN-607
Please request a quotation for a real price and lead time.
