405 nm LD Pumped All-Solid-State Single Longitudinal Mode CW Laser MSL-T-405
$1,000,000.00
Description: All solid state single longitudinal mode laser features ultra compact, long lifetime, low cost and easy operating.
Applications: atomic physics, quantum optics, metrology, spectroscopy, scientific research
Model #: MSL-T-405
| Model | MSL-T-405 |
| Wavelength | 405 nm |
| Operation Mode | CW |
| Longitudinal Mode | Single |
| Output Power | 1-80 mW |
| Spectral Line Width | <0.000005 nm (<10MHz) |
| Coherent Length | >30 m |
| Power Stability | <1%, <0.5% |
| Beam Divergence, Full Angle | <1 mrad |
| Beam Diameter at the Aperture | <2 mm |
| M2 | <1.2 |
| Noise of Amplitude (rms, 20Hz-20MHz) | <0.5% |
| Polarization Ratio | >100:1, Vertical (Horizontal optional) |
| Beam Height from Base Plate | 51 mm |
| Cooling Method | Water cooled |
| Operating Temperature | 15 ~ 35 ℃ |
| Power Supply (220/110VAC) | RAD1PS |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MSL-T-405
Please request a quotation for a real price and lead time.
