NS-FH-1064 1064 nm Nanosecond Fiber Laser
$1,000,000.00
Description: High power nanosecond fiber laser at 1064 nm with high repetition rate and short pulse duration.
Applications: marking, micro-machining, scientific research
Model #: NS-FH-1064
| Wavelength (nm) | 1064±1 |
| Average Power (W) | 1-60 |
| Single Pulse Energy (µJ) | 200 µJ @200 kHz; 60 µJ @1 MHz; 40 µJ @1.5 MHz |
| Rep. Rate | 0.2-10 MHz |
| Pulse Duration (ns) | 2-10 ns @1.5 MHz |
| Peak Power (MW) | 1-20 |
| Average Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| Warm-up Time (minutes) | <10 |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | <1 |
| Beam Diameter at the Aperture (1/e2, mm) | <3 |
| M2 | <1.3 |
| Polarization Ratio | >100:1 Vertical |
| Beam Height from Base Plate (mm) | 114 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-35 |
| Power Supply (100-240 VAC) | RAD1PS |
| Expected Lifetime (hours) | >1000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # NS-FH-1064
Please request a quotation for a real price and lead time.
