OEM-S-545-MD 545 nm OEM Green Laser Module
$1,000,000.00
Description: The all-solid-state laser features high output power stability, an excellent beam profile, an ultra-compact design and long lifetime.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: OEM-S-545-MD
| Model | OEM-S-545-MD |
| Wavelength (nm) | 545±1 |
| Operating Mode | CW |
| Output Mode | Free space output / Fiber coupling output |
| Output Power (mW)¹ | 1-1000 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Beam Mode | Longitudinal: Multimode; Transverse: TEM01 |
| Beam Diameter at the Aperture (1/e², mm) | <1.5 |
| Beam Divergence, Full Angle (mrad) | <30 |
| Fiber Core Diameter² | 200µm (fiber coupling output) |
| Fiber Connector³ | FC/PC (fiber coupling output) |
| Fiber Length⁴ | 1m (fiber coupling output) |
| Warm-Up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 15.6 |
| Maximum Current (mA) | 4000 |
| Operating Voltage (VDC) | 5 |
| Thermistor Resistance | 10kΩ @ 25°C |
| Power Consumption (W) | <20 |
| Storage Temperature (℃) | 0-60 |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # OEM-S-545-MD
Please request a quotation for a real price and lead time.
