PGL-F Series Diode Laser Module
$1,000,000.00
Description: Multi-wavelength diode laser module with low noise and PC control.
Applications: collimation, laser medical treatment, scientific experiment, optical instrument
Model #: PGL-F
| Model | PGL-F |
| Wavelength (nm) | 405 / 450 / 488 / 520 / 637 / 660 / 685 / 785 / 830 / 850 / 940 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 50 (405-940) / 20 (488) |
| Operating Mode | CW / PC control |
| Noise of Amplitude (rms) | <1%, <0.5% |
| Modulation Frequency (kHz) | 0.1-50 |
| Pointing Stability (mrad/℃) | <0.05 |
| Warm-Up Time (minutes) | <5 |
| Expected Lifetime (hours) | 10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-F
Please request a quotation for a real price and lead time.
