PGL-FS-520 520 nm Compact Green Laser Module
$1,000,000.00
Description: PGL-FS green laser module features small size, high output power and long lifetime.
Applications: collimation, laser medical treatment, scientific experiment, optical instrument
Model #: PGL-FS-520
| Model | PGL-FS-520 |
| Wavelength (nm) | 520 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-100 |
| Power Stability (rms, over 4 hours) | <5%, <3%, <1% |
| Operating Mode | CW |
| Transverse Mode | Near TEM00 |
| Beam Diameter at the Aperture (1/e², mm) | ~4.5 |
| Beam Divergence, Full Angle (mrad) | <1 |
| Warm-Up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 15 |
| Expected Lifetime (hours) | 10000 |
| Warranty (years) | 1 |
| Operating Voltage (PSU-II-OEM) | 7V (TTL 30kHz or Analog 0-5V, optional) |
| Operating Voltage (PSU-V-OEM) | 100-240VAC (TTL 30kHz and Analog 0-5V) |
| Connection | Cable with flying leads |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-FS-520
Please request a quotation for a real price and lead time.
