PGL-H-655 655 nm High Power Red Laser Module
$1,000,000.00
Description: High power red diode laser module at 655nm with ultra compact design, long lifetime, low cost and easy operating. Ideal for integration into customer equipment.
Applications: measurement, spectrum analysis, laser lighting show, instrumentation
Model #: PGL-H-655
| Wavelength (nm) | 655 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-800 |
| Operating Mode | CW |
| Transverse Mode | Multimode |
| Beam Diameter at Aperture (1/e², mm) | ~2×4 |
| Beam Divergence, Full Angle (mrad) | <4×0.5 |
| Working Time (seconds) | 30 |
| Expected Lifetime (hours) | 10000 |
| Warranty (years) | 1 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-H-655
Please request a quotation for a real price and lead time.
