PGL-LF-1450 1450 nm Line Beam Adjustable Focus Diode Laser Module
$1,000,000.00
Description: PGL-LF series diode laser module at 1450 nm whose beam size can easily be adjusted with the tool-free manual focus option.
Applications: collimation, laser medical treatment, scientific experiment, optical instrument
Model #: PGL-LF-1450
| Wavelength (nm) | 1450 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-10 |
| Beam Size | <250 mm (adjustable) |
| Beam Size @1 m | <1.0 mm |
| Beam Divergence (mrad) | <1.5 |
| Laser Operation Mode | CW |
| Expected Lifetime (hours) | 10000 |
| Warranty (year) | 1 |
| Operating Voltage (Internal PCB) | DC 5 V |
| Modulation Optional | TTL 30 kHz or analog (0-3 V or 0-5 V) |
| Connection | Cable with flying leads |
| Operating Temperature (°C) | -10 to +45 |
| Storage Temperature (°C) | -20 to +80 |
| Humidity | <90%, non-condensing |
| Dissipated Heat (W) | <1 |
| Weight (g) | 45 |
| Length (mm) | 95 |
| Diameter Head Φ (mm) | 18 |
| Material | Aluminum |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-LF-1450
Please request a quotation for a real price and lead time.
