PGL-V-H-1480 1480 nm Diode Laser Module
$1,000,000.00
Description: Diode infrared laser module at 1480 nm featuring ultra compact design, long lifetime, low cost and easy operating.
Applications: measurement, communication and spectrum analysis, etc.
Model #: PGL-V-H-1480
| Wavelength (nm) | 1480 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-1000 |
| Power Stability (rms, over 4 hours) | <5%, <3%, <1% |
| Operating Mode | CW |
| Transverse Mode | Multimode |
| Beam Diameter at the Aperture (1/e2, mm) | ~4×6 |
| Beam Divergence, Full Angle (mrad) | <10 |
| Warm-up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 15 |
| Expected Lifetime (hours) | 10000 |
| Warranty (years) | 1 |
| Operating Voltage (PSU-V-OEM) | 100-240 VAC |
| Operating Voltage (PSU-I-OEM) | 12 VDC |
| Modulation Optional | TTL 30 kHz and Analog 0-5 V |
| Connection | 9 pin connector |
| Operating Temperature (°C) | -10 to 50 |
| Storage Temperature (°C) | -20 to 80 |
| Humidity | <90%, non-condensing |
| Dimensions of Laser Head | 92 (L) ×40 (W) ×40 (H) mm |
| Material | Aluminum |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-V-H-1480
Please request a quotation for a real price and lead time.
