450 nm Diode Laser Module PGL-V-H-450
$1,000,000.00
Description: Compact diode laser module with long lifetime and easy operating.
Applications: collimation, laser medical treatment, scientific experiment, optical instrument
Model #: PGL-V-H-450
| Model | PGL-V-H-450 |
| Wavelength | 450 nm |
| Wavelength (nm) | 445 / 447 / 450 |
| Wavelength tolerance (nm) | ±10 |
| Output power (mW) | 1-80 / 1-3000 |
| Power stability (rms, over 4 hours) | <5%, <3%, <1% |
| Operating mode | CW |
| Transverse mode | Near TEM00 / Multimode |
| Beam diameter at the aperture (1/e², mm) | ~4.5 / ~2×4 |
| Beam divergence, full angle (mrad) | <1.5 / <3×0.5 |
| Warm-up time (minutes) | <10 |
| Beam height from base plate (mm) | 15 |
| Expected lifetime (hours) | 10000 |
| Warranty (years) | 1 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-V-H-450
Please request a quotation for a real price and lead time.
