PGL-V-H-462 462 nm Compact Blue Diode Laser Module
$1,000,000.00
Description: Diode blue laser module is made features of ultra compact, long lifetime, low cost and easy operating, which made it be used widely in laser pointing, show and light applications. High quality beam properties make it useful in RGB mixed laser systems.
Applications: laser pointing, laser show and light applications, RGB mixed laser systems
Model #: PGL-V-H-462
| Model | PGL-V-H-462 |
| Wavelength (nm) | 462 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-2000 |
| Power Stability (rms, over 4 hours) | <5%, <3%, <1% |
| Operating Mode | CW |
| Transverse Mode | Multimode |
| Beam Diameter at the Aperture (1/e², mm) | ~2×4 |
| Beam Divergence, Full Angle (mrad) | <3×0.5 |
| Warm-Up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 15 |
| Expected Lifetime (hours) | 10000 |
| Warranty (months) | 12 |
| Operating Voltage (PSU-V-OEM) | 100-240VAC |
| Operating Voltage (PSU-I-OEM) | 12VDC |
| Modulation | TTL 30kHz and Analog 0-5V |
| Connection | 9 pin connector |
| Operating Temperature (℃) | -10 to 50 |
| Storage Temperature (℃) | -20 to 80 |
| Humidity | <90%, non-condensing |
| Dimensions of Laser Head | 92 (L) ×40 (W) ×40 (H) mm |
| Material | Aluminum |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-V-H-462
Please request a quotation for a real price and lead time.
