PGL-VI-1550 1550 nm Diode Laser Module
$1,000,000.00
Description: Diode infrared laser module at 1550 nm featuring wide range temperature operating (without TEC), high reliability and low cost.
Applications: orientation, alignment and measurement, etc.
Model #: PGL-VI-1550
| Wavelength (nm) | 1550 |
| Wavelength Tolerance (nm) | ±10 |
| Output Power (mW) | 1-15 |
| Operating Mode | CW |
| Transverse Mode | Near TEM00 |
| Beam Diameter at the Aperture (1/e2, mm) | ~3.5 |
| Beam Divergence, Full Angle (mrad) | <3 |
| Expected Lifetime (hours) | 10000 |
| Warranty (years) | 1 |
| Operating Voltage (Internal PCB) | 3 VDC (TTL 10 kHz, optional) / 5 VDC (TTL 30 kHz or Analog 0-3 V, 0-5 V, optional) |
| Connection | Cable with flying leads |
| Operating Temperature (°C) | 0 to 40 |
| Storage Temperature (°C) | -20 to 80 |
| Humidity | <90%, non-condensing |
| Dissipated Heat (W) | <1.5 |
| Laser Head Diameter Φ (mm) | 15 |
| Length (mm) | 90 |
| Material | Aluminum |
| Shell Polarity | The housing is isolated. |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-VI-1550
Please request a quotation for a real price and lead time.
