PGL-VI-589 589 nm Compact Blue Laser Module
$1,000,000.00
Description: All solid state orange laser at 589nm is made features of ultra compact, long lifetime, low cost and easy operating, which made it be used widely in scientific experiment, optical sensor, measurement, instrument, communication and spectrum analysis, etc.
Applications: scientific experiment, optical sensor, measurement, instrument, communication and spectrum analysis
Model #: PGL-VI-589
| Wavelength (nm) | 589±2 |
| Wavelength Tolerance (nm) | ±2 |
| Output Power (mW) | 1-20 |
| Operating Mode | CW |
| Transverse Mode | TEM00 |
| Beam Diameter at Aperture (1/e², mm) | ~1.5 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Expected Lifetime (hours) | 10000 |
| Warranty | 1 year |
| Operating Voltage (internal PCB) | 3VDC |
| Operating Voltage (external PCB) | 3VDC |
| Connection | Cable with flying leads |
| Operating Temperature | 10°C to 35°C |
| Storage Temperature | -20°C to 80°C |
| Humidity | <90%, non-condensing |
| Dissipated Heat | <6W |
| Dimensions of PGL-VI-589 | Φ20×100 mm |
| Dimensions of PGL-VI-1-589 | Φ15×65 mm |
| Material | Aluminum/Copper |
| Shell Polarity | The housing has a positive electrode. |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PGL-VI-589
Please request a quotation for a real price and lead time.
