PIL-VI-1064 1064 nm Compact Infrared Laser Module
$1,000,000.00
Description: Compact OEM infrared laser module at 1064 nm. Ideal for integration into customer systems.
Applications: OEM systems, measurement, machine vision
Model #: PIL-VI-1064
| Wavelength (nm) | 1064 |
| Wavelength Tolerance (nm) | ±1 |
| Output Power (mW) | 1-100 |
| Operating Mode | CW |
| Transverse Mode | TEM00 |
| Beam Diameter at the Aperture (1/e2, mm) | ~1.5 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Expected Lifetime (hours) | 10000 |
| Warranty (years) | 1 |
| Operating Voltage (Internal) | 3 VDC (TTL 10 kHz, optional) |
| Operating Voltage (External 1 PCB) | 3 VDC |
| Operating Voltage (External 2 PCB) | 5 VDC |
| Connection | Cable with flying leads |
| Operating Temperature | 10 °C to 35 °C |
| Storage Temperature | -20 °C to 80 °C |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PIL-VI-1064
Please request a quotation for a real price and lead time.
