PS-HG-515A 515 nm Picosecond Pulsed Laser
$1,000,000.00
Description: Picosecond pulsed laser at 515nm is made features of short pulse duration, high repetition rate, high stability and good beam quality.
Applications: sapphire marking, ceramic cutting, semiconductor cutting, film scribing, physics experiment
Model #: PS-HG-515A
| Model | PS-HG-515A |
| Wavelength (nm) | 515±1 |
| Operating Mode | Pulsed |
| Average Power (W)¹ | 1-20 |
| Single Pulse Energy (µJ) | 0.05-1 |
| Repetition Rate (MHz)² | 20-120 |
| Pulse Duration (ps)³ | 10-150 |
| Ave Power Stability (rms, 4 hours ±3°C) | <5%, <3% |
| Warm-Up Time (minutes) | <10 |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Beam Diameter at the Aperture (1/e², mm) | <3 |
| M² | <1.3 |
| Polarization Ratio | >100:1, Horizontal |
| Beam Height from Base Plate (mm) | 122 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 10-35 |
| Power Supply (100-240VAC) | RAD1PS |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PS-HG-515A
Please request a quotation for a real price and lead time.
