660 nm Raman Picosecond Pulsed Laser PS-M-660
$1,000,000.00
Description: Raman picosecond pulsed laser at 280-660nm features short pulse duration, high repetition rate and high average power.
Applications: industrial processing, physics experiment
Model #: PS-M-660
| Model | PS-M-660 |
| Wavelength | 660 nm |
| Operation Mode | Pulsed (Q-switched) |
| Average Power | 1-300mW (300mW@1MHz) |
| Single Pulse Energy | 1-300nJ (300nJ@1MHz) |
| Pulse Width | 10ps @1MHz, 300mW |
| Peak Power | 30 kW @1MHz |
| Repetition Rate | 500-1000 kHz |
| Power Stability | <3%, (<2% optional) |
| Beam Divergence, Full Angle | <1 mrad |
| Beam Diameter at the Aperture | ~3.0 mm |
| Beam Height from Base Plate | 116 mm |
| Cooling Method | Water cooled |
| Operating Temperature | 15 ~ 35 ℃ |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # PS-M-660
Please request a quotation for a real price and lead time.
