S400 LDF Large Diameter Fiber Fusion Splicer

The S400 LDF specialty fusion splicer is a new model with innovative technologies for the special splicing needs of factory, manufacturing, laboratory and R&D applications. Users can splice large-diameter fibers (125 – 500 µm) with the S400 LDF Specialty Fiber Fusion Splicer.

Key Features

• Splices large-diameter fiber with cladding diameters of 125 – 500 µm.
• Real-time ARC automatic calibration.
• High resolution 5-inch touch screen.
• Typical splice time 8 – 10 seconds; typical heating time 20 seconds (60 mm heating tube).
• Electrode life: typical 3000 times discharge.
• Data storage: 10,000 groups of records and 100 group images.
• 5,200 mAh Li-battery; AC adapter input AC 100 – 240 V (50/60 Hz), output DC 13.5 V / 4.5 A.

Data Sheet: S400 LDF Large Diameter Fiber Fusion Splicer (PDF)
