SF-D-1550 1550 nm Narrow Linewidth Single Frequency Diode Laser Module
$1,000,000.00
Description: Infrared diode laser module at 1550 nm featuring single frequency, compact package and convenient operation.
Applications: measurement, communication, spectrum analysis, etc.
Model #: SF-D-1550
| Wavelength (nm) | 1550±5 |
| Operating Mode | CW |
| Output Power After Fiber (mW) | 1-15 |
| Power Stability (rms, over 4 hours) | <1%, <2%, <3% |
| Fiber Type | Single mode fiber |
| Linewidth (kHz) | ~10 |
| Side Mode Suppression Ratio (dB) | >35 |
| Polarization Extinction Ratio (dB) | >15 |
| Warm-up Time (minutes) | <5 |
| Operating Temperature (°C) | 10-35 |
| Expected Lifetime (hours) | 10000 |
| Warranty | 1 year |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # SF-D-1550
Please request a quotation for a real price and lead time.
