TEM-F-1273DFB 1273 nm DFB Diode Laser
$1,000,000.00
Description: DFB (distributed feedback) diode laser at 1273 nm featuring TEM00 mode, ultra compact design and narrow spectral linewidth.
Applications: gas detection, measurement, spectroscopy
Model #: TEM-F-1273DFB
| Central Wavelength (nm) | 1273±2 |
| Spectral Line Width (MHz) | ~3 |
| Operating Mode | CW |
| Output Power (mW) | 1-10 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Transverse Mode | TEM00 |
| M2 | ~1.0 |
| Beam Diameter at the Aperture (1/e2, mm) | ~1.0 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Warm-up Time (minutes) | <5 |
| Operating Temperature (°C) | 25±3 |
| Power Supply (100-240 VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # TEM-F-1273DFB
Please request a quotation for a real price and lead time.
