TUN-TiA-393-408 393-408 nm LD Pumped All-Solid-State Q-switched Tunable Laser
$1,000,000.00
Description: All solid state Q-switched violet blue laser at 393~408nm is customizable at any wavelength of this range.
Applications: marking, carving, measure, scientific research
Model #: TUN-TiA-393-408
| Model | TUN-TiA-393-408 |
| Wavelength (nm)¹ | 393-403 / 404-408 |
| Operating Mode | Acousto-Optic Q-switched |
| Average Power (mW) | 1-1000 / 1-500 |
| Pulse Duration (ns) | ~35 @50kHz |
| Rep. Rate (kHz)² | 10-50 |
| Single Pulse Energy (µJ) | 1-20 @50kHz |
| Peak Power (kW) | 0.1-0.57 @50kHz |
| Ave Power Stability (rms, 4 hours±3℃) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <4 |
| Beam Diameter at the Aperture (1/e², mm) | 3 |
| Beam Height from Base Plate (mm) | 132 |
| Warm-Up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-35 |
| Power Supply (100-240VAC) | PSU-AOM (3U) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # TUN-TiA-393-408
Please request a quotation for a real price and lead time.
