TUN-TiL-780-850 780-850 nm Q-Switched Ti:Sapphire Laser
$1,000,000.00
Description: All solid state Q-switched Ti:Sapphire laser at 780-850nm, widely used in marking, carving, measure, scientific research.
Applications: marking, carving, measure, scientific research
Model #: TUN-TiL-780-850
| Model | TUN-TiL-780-850 |
| Wavelength (nm) | 780-850 |
| Operating Mode | Actively Q-switched |
| Average Power (mW) | 1-500 @5kHz |
| Pulse Duration (ns) | ~10 |
| Repetition Rate (kHz) | 1-5 |
| Single Pulse Energy (µJ) | 1-100 @5kHz |
| Peak Power (kW) | 0.1-1 @5kHz |
| Average Power Stability (rms, 4 hours ±3°C) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter at the Aperture (1/e², mm) | <2 |
| Beam Height from Base Plate (mm) | 111 |
| Warm-Up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-35 |
| Power Supply (100-240VAC) | PSU-AOM |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # TUN-TiL-780-850
Please request a quotation for a real price and lead time.
