TUN-V-2916-3918 2916-3918 nm Wavelength Tunable Mid-Infrared Laser
$1,000,000.00
Description: LD pumped all-solid-state mid-infrared laser covering 2916-3918 nm with CW output power of up to 400 mW and a wide tuning range. Any wavelength range in the list can be ordered.
Applications: remote sensing, communication, spectrum analysis, etc.
Model #: TUN-V-2916-3918
| Wavelength (nm) | 2916-2992 / 3000-3200 / 3393-3575 / 3619-3784 / 3815-3918 |
| Wavelength Deviation (nm) | ±5 |
| Operating Mode | CW |
| Output Power (mW) | 1-400 (per band: 1-400 / 1-200 / 1-300 / 1-100 / 1-100) |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <5 (3815-3918: <8) |
| Beam Diameter at the Aperture (1/e2, mm) | <6 / <7 / <8 |
| Beam Height from Base Plate (mm) | 82 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air Cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (100-240 VAC) | RAD1PS |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # TUN-V-2916-3918
Please request a quotation for a real price and lead time.
