261 nm LD Pumped All-Solid-State Single Longitudinal Mode CW UV Laser UV-DP-261-LN
$1,000,000.00
Description: Low noise all solid state laser features ultra compact, easy operating, high power and stability.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: UV-DP-261-LN
| Model | UV-DP-261-LN |
| Wavelength | 261 nm |
| Operation Mode | CW |
| Average Power | 1-500 / 500-800 mW |
| Power Stability | <2%, <1%, <0.5% |
| Transverse Mode | TEM00 |
| Spectral Line Width | <0.2, <0.003 / <0.2 |
| Longitudinal Mode | Single |
| Coherent Length | >50 m |
| Noise of Amplitude (rms, 20Hz-20MHz) | <1%, <0.5% |
| Warm-Up Time | < 10 min. |
| Operating Temperature | 10 ~ 35 ℃ |
| Power Supply (100-240VAC) | PSU-H-FDA |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # UV-DP-261-LN
Please request a quotation for a real price and lead time.
