320 nm LD Pumped All-Solid-State Single Longitudinal Mode CW UV Laser UV-FN-320-SLM
$1,000,000.00
Description: An all-solid-state single longitudinal mode UV laser is characterized by high output power stability, a good beam profile, ultra-compactness, a long lifetime and easy operation.
Applications: high-precision measurement, interferometry, spectroscopy, scientific research
Model #: UV-FN-320-SLM
| Model | UV-FN-320-SLM |
| Wavelength | 320 nm |
| Operation Mode | CW |
| Average Power | 50-100 mW |
| Power Stability | <1%, <0.5% |
| Transverse Mode | TEM00 |
| M2 | <1.2 |
| Longitudinal Mode | Single |
| Coherent Length | >50 m |
| Noise of Amplitude (rms, 20Hz-20MHz) | <1%, <0.5% |
| Warm-Up Time | < 10 min. |
| Operating Temperature | 10 ~ 35 ℃ |
| Power Supply (100-240VAC) | PSU-H-FDA |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # UV-FN-320-SLM
Please request a quotation for a real price and lead time.
