349 nm LD Pumped All-Solid-State CW UV Laser UV-FN-349-SM
$1,000,000.00
Description: CNI has a long experience in the delivery of fiber coupled laser light sources providing high efficiency and long term stability.
Applications: fiber coupled laser applications, scientific research, optical instrument
Model #: UV-FN-349-SM
| Model | UV-FN-349-SM |
| Wavelength | 349 nm |
| Operation Mode | CW |
| Average Power | 1-50 mW |
| Power Stability | <3%, <2%, <1% |
| Transverse Mode | TEM00 |
| M2 | <1.2 |
| Polarization (optional) | >50:1 after PM fiber (>100:1 optional) |
| Fiber Connector | FC/APC |
| Fiber Jacket | PVC |
| Fiber Length | 1m |
| Warm-Up Time | < 10 min. |
| Operating Temperature | 10 ~ 35 ℃ |
| Modulation Option | DC-1kHz; TTL and Analog optional |
| Power Supply | PSU-H-FDA/PSU-H-LED/PSU-SR |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # UV-FN-349-SM
Please request a quotation for a real price and lead time.
