370 nm LD Pumped All-Solid-State CW UV Laser UV-SF-370
$1,000,000.00
Description: All solid-state CW mode UV laser features ultra compact, easy operating, high power and stability.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: UV-SF-370
| Model | UV-SF-370 |
| Wavelength | 370 nm |
| Operation Mode | CW |
| Average Power | 1-20 mW |
| Power Stability | <3%, <2%, (<1% optional @ Water cooled) |
| Transverse Mode | TEM00 |
| M2 | ~3.0 |
| Beam Diameter at the Aperture | ~3.0 mm |
| Beam Divergence, Full Angle | <2.0 mrad |
| Warm-Up Time | < 10 min. |
| Beam Height from Base Plate | 45 mm (Air) / 61.5 mm (Water) |
| Cooling Method | Water cooled (WCH-580) |
| Power Supply | PSU-SF |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # UV-SF-370
Please request a quotation for a real price and lead time.
