YL-I-465-1-20W 465 nm Fiber-Coupled Diode Laser
$1,000,000.00
Description: The 465nm diode laser features an ultra-compact design, a long lifetime, and easy operation. It is also easy to install in customers’ equipment.
Applications: medical treatment, ultra compact OEM integration
Model #: YL-I-465-1-20W
| Model | YL-I-465-1-20W |
| Wavelength (nm) | 465±5 |
| Operating Mode | CW |
| Output Power (W) @ after 400µm fiber¹ | 1-20 |
| Fiber Core Diameter (µm) | 100, 200, 400, 600, 0.22NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length² | 1m |
| Fiber Jacket | PVC, Metal optional |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Cooled Method | Air cooled |
| Warm-Up Time (minutes) | <5 |
| Operating Temperature (℃) | 0-30 |
| Operating Voltage (VAC) | 100-240 |
| Modulation Option | DC-1kHz, 1kHz-10kHz, 10kHz-50kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # YL-I-465-1-20W
Please request a quotation for a real price and lead time.
