YL-I-638-808-980-1470-62W Multi-Wavelength Fiber-Coupled Laser System
$1,000,000.00
Description: The 638/808/980/1470nm diode laser features an ultra-compact design, a long lifetime, and easy operation. It is also easy to install in customers' equipment.
Applications: scientific research, industrial and medical applications
Model #: YL-I-638-808-980-1470-62W
| Wavelength (nm) | ['638±10', '808±10', '980±10', '1470±10'] |
| Output Power (W) @ after 200µm fiber | ['0.4', '22', '30', '10'] |
| Operation Voltage (V) | ['2.3', '3.6', '4.65', '6.4'] |
| Operation Current (A) | ['1.2', '12', '13', '9'] |
| Fiber Core Diameter (µm) | ['200, 400, 600, 0.22NA'] |
| Fiber Connector | ['SMA905, FC/PC optional'] |
| Fiber Length | ['1 m'] |
| Fiber Jacket | ['PVC, Metal optional'] |
| Power Stability (rms, 4 hours ±3℃) | ['<2%, <1%'] |
| Cooling Method | ['Air cooled'] |
| Operation Temperature (℃) | ['15-35'] |
| Storage Temperature (℃) | ['-20-50'] |
| Modulation Option | ['DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional'] |
| Expected Lifetime (hours) | ['>10000'] |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # YL-I-638-808-980-1470-62W
Please request a quotation for a real price and lead time.
